8K Streaming Encoder “e8”
Features
- 8K60p real-time streaming of video shooting by 8K camera
- Easy to use and small body size (W:370㎜ × D:350㎜ × H:70㎜)
- Provided with 8K Media Player
●8K live streaming system
Application
- Public screening of events
- Live streaming in organization
- Real-time monitoring for medical
- 8K-VR streaming
Specifications
| Item | Specification | |
|---|---|---|
| Interface | Input | Connector : 12G-SDI x 4ch, BNC type |
| Video : 8K, 2 sample interleave | ||
| Audio : SDI embedded audio | ||
| Output | Gigabit Ethernet x 2ch | |
| USB3.0 x 2ch (for recording) | ||
| Encoding Function |
Video | Resolution : 7680 x 4320 pixel |
| Pixel format : 10bit, 8bit / 4:2:2, 4:2:0 | ||
| Framerate : 60, 59.94, 50, 30, 29.97, 25, 24, 23.98 | ||
| Encoding format : HEVC | ||
| Bitrate : 60Mbps – 200Mbps | ||
| Support embedding HDR parameters | ||
| Audio | Encoding format : AAC LC, Pass-through | |
| Channel : 2ch | ||
| Streaming Function |
Streaming Protocol |
HTTP Live Streaming (HLS) |
| RTMP (with proprietary extension) | ||
| RTP (with or w/o FEC) | ||
| UDP | ||
| SRT | ||
| Container Format |
MPEG2-TS | |
| Recoding Function |
Supported Storage |
USB memory |
| File Format | MP4, MPEG2-TS, Video-ES | |
| Chassis | User Interface | Buttons and LCD display on front panel |
| Dimensions | 370mm (W) x 350mm (D) x 70mm (H) | |
| Power Supply | 100 – 240V | |
| Others | Certification | CE |
| FCC Class A | ||
| CCC | ||
* This specification is subject to change without notice.
Download
-
●Catalog
8K Streaming Encoder “e8” [PDF] -
●Manual
8K Streaming Encoder "e8" User's Manual [PDF] -
●Software update
v1.3g (binary) (release note)2020/6/12
Related Product
Inquiries about products
Please use “Inquiry form” to inquire about the product details.
