图形显示控制器 SC1701 Series

图形显示控制器 SC1701 Series

图形显示控制器 SC1701 Series
  • 技术问题
  • 索取技术文档

Socionext的图形显示控制器SC1701 Series,凭借面向多种车载远程显示用途而优化的解决方案,实现能够削减BOM和具有成本竞争力的系统。

SC1701 Series内置了双显示控制器,因此可通过单个链接接收和显示两个不同视频流,有助于实现灵活的体系结构设计。
在非压缩情况下最多支持9.6Gbps,而在利用VESA DSC压缩方式的情况下,最多支持28Gbps的视频,因此其设计也能够满足未来的需求。此外,通过签名单元还可以验证安全性和数据的完整性。

特长

  • 4k Resolution (3840 x 2160 @ 60Hz / 30bpp)
  • Socionext SEERIS® 2D Graphics Engine
  • Dual Display Controller and dual TCON integrated
  • Signature Unit and Safety layer
  • Optional APIX®3 receiver up to 12 Gbps with HDCP 1.4
  • Ethernet extension support through APIX®3
  • VESA DSC decompression up to 3:1 ratio
  • Display Output Interfaces (OpenLDI, miniLVDS, RSDS, TTL)
  • Touch Controller connectivity and Audio Generator
  • Wide range of peripherals for external connectivity
  • Spread Spectrum Modulation to reduce EMI
  • AEC-Q100 qualification
  • Support for Automotive Safety and Integrity (ASIL B)
  • 2 package variants for design and BOM flexibility

*:SEERIS是Socionext公司的注册商标。

Display Domain Architecture

Display Domain Architecture

规格

Features SC1701BK3 SC1701BH5
Package – Pin HS – BGA – 319 EP – LQFP – 216
Size, Pitch 23x23mm, 1.0mm 24x24mm, 0.4mm
2D Core Socionext SEERIS®-MVL Socionext SEERIS®-MVL
Video Channels 2 1
Video Output Resolution 1x3840x2160 @ 60fps (30bit)
2x2560x1600 @ 60fps (30bit)
1x1920x1080 @ 60fps (30bit)
Video Output Dual TCON-RSDS
2x 6 pair miniLVDS, TTL
2x dual LVDS (OpenLDI)
TCON-RSDS
6 pair miniLVDS, TTL
dual LVDS (OpenLDI)
Video Formats
Decompression
RGBA or YUV4:4:4 / 4:2:2
VESA DSC v1.2 (2:1/3:1)
RGBA or YUV4:4:4 / 4:2:2
VESA DSC v1.2 (2:1/3:1)
Pixel Speed 2x266MPix/s or 1x533Mpix/s 266MPix/s
Signature Units 2 x 8 8
Image Processing CLUT, Matrix, Dither, Gamma,
Sprites, α blending, scaling
CLUT, Matrix, Dither, Gamma,
Sprites, α blending, scaling
Audio I²S over APIX®3, Sound Generator
APIX® Down – Up APIX®3 @ 12Gbps - 187 Mbps APIX®3 @ 6Gbps - 187 Mbps
Content Protection HDCP 1.4 (APIX®3)
Network MII - Ethernet over APIX®3 @ 100 Mbps
Option Available also without APIX®3 Rx and related features
Daisy Chain Yes, requires external Tx -
Video input / Capture Dual MIPI-DSI v1.2, dualLVDS (OpenLDI)
SRAM – Flash 256K (9KB ECC) - 128K
Standard I/O USART-LIN, I²C, GPIO, PWM, ADC, HS-SPI, CAN listener
Stepper Motor Control 6
Qualification AEC-Q100, Ta -40 … +105°C

文档

●产品目录

●技术文档

关于下面的技术资料,烦请您通过表单提出要求。

  • Hardware Manual
  • Register Description
  • Evaluation Board Manual
  • PCB Guideline
索取技术文档

关于本产品的咨询

有关详细信息,请使用咨询表联系我们。
