High-speed video interface bridge LSI "HV series"
High-speed video interface bridge LSI "HV series"
"HV series" that are high-speed video interface bridge LSIs with color space conversion are based on the combination of high-speed video interface technology and advanced image processing technology. They provide a video interface conversion between HDMI, V-by-One® HS and HS-LVDS for Full-HD(2K)/ UHD(4K) contents.
Features
- Support Full-HD (2K)/ UHD (4K)
- Up-scale conversion : Full-HD (2K) to UHD (4K)
- Down-scale conversion : UHD (4K) to Full-HD (2K)
- Low delay (less than 0.1 frame)
- Support HDMI 2.0 (6Gbps for 4K/60p)
- Support HDCP 1.4/ 2.2 (Copyright protection)
Product Line-up
[Basic functions: Interface bridge]
| Product No. | INPUT | OUTPUT | Note |
|---|---|---|---|
| MN869124 | HDMI | HDMI | Color space conversion |
| MN869125 | HDMI | V-by-One® HS | Color space conversion |
| MN869126 | HDMI | HS-LVDS | Color space conversion |
| MN869127 | V-by-One® HS | HDMI | Color space conversion |
| MN869128 | V-by-One® HS | V-by-One® HS | Color space conversion |
"V-by-One®" is a registered trademark of the THine Electronics, Inc.
[Optional functions: Example of scale conversion]
-
Up-scale conversion ：
Full-HD (2K) → UHD (4K)
-
Down-scale conversion ：
UHD (4K) → Full-HD (2K)
Product Catalog
- High-speed video interface bridge LSI "HV series" MN869124 catalog [PDF]
- High-speed video interface bridge LSI "HV series "MN869125 catalog [PDF]
- High-speed video interface bridge LSI "HV series“ MN869126 catalog [PDF]
- High-speed video interface bridge LSI "HV series" MN869127 catalog [PDF]
- High-speed video interface bridge LSI "HV series" MN869128 catalog [PDF]
